2K (±1K tolerance) at +25°C (+77°F), 50% RH |
4% RH (±1% tolerance) at +25°C (+77°F), 50% RH |
approx. 5 sec. |
change-over contact (relay) |
VDE: NO/NC > 15,000 cycles UL: NO/NC > 30,000 cycles |
240VAC, 10 (1.6) A 60VDC, 0.6A1 |
AC 30A for 10 sec. |
LED |
5-pole terminal, clamping torque 0.5Nm max.: rigid/stranded2 wire 2.5mm2 (AWG 14) |
clip for 35mm DIN rail, EN 60715 |
plastic according to UL94 V-0, light grey |
77 x 60 x 43mm |
approx. 0.2kg |
vertical |
-40 to +60°C (-40 to +140°F) |
max. 90% RH (non-condensing) |
IP20 |
VDE, UL File No. E164102, EAC |
1 not UL confirmed
2 When connecting with stranded wires, wire end ferrules must be used.
01230.0-00 | 100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC) | 0 to +60°C | 50 to 90% RH |
01230.9-00 | 100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC) | +32 to +140°F | 50 to 90% RH |
01230.1-00
|
24-48VDC (min. 20VDC, max. 60VDC) | 0 to +60°C |
50 to 90% RH
|
