MECHANICAL JUMPER CLAMPS
? Two sizes available - 6 solid through 556.5 MCM and 6 solid through 954 ACSR
? Easy to install
? Thrust bearing design provides low friction for tightening clamp
? Bronze clamping rings have serrated contact surface to insure good electrical contact with conductors
? Two styles available...
Yellow handles are made from bright yellow, impact resistant modified polyolefin material
Clear handles are made from a high impact plastic material
? Grip tabs are molded in for easy gripping with rubber gloves
? Conductor clamp is machined from brass alloy
? Rated for 400 amps continuous current maximum rating - this rating is dependent on the rating of the
jumper cable used with the clamps
![2013072550301081[1]](http://cbu01.alicdn.com/img/ibank/2013/636/919/1049919636_1086601265.jpg)
|
CAT NO |
DESCRIPTION |
MAIN LINE RANGE |
JUMPER CABLE RANGE |
LBS |
||
|
|
|
MAXIMUM |
MINIMUM |
MAXIMUM |
MINIMUM |
|
|
13004 |
MEDIUM RANGE JUMPER CLAMP YELLOW |
556-5 MCM OR 477 ACSR |
6 SOLID .162 DIA |
4/0 15KV* |
#2 |
1.6 |
|
13765 |
MEDIUM RANGE JUMPER CLAMP CLEAR |
556-5 MCM OR 477 ACSR |
6 SOLID .162 DIA |
4/0 15KV* |
#2 15KV |
1.6 |
|
11000 |
LARGE RANGE JUMPER CLAMP YELLOW |
954 ACSR 36/1 |
6 SOLID .162 DIA |
4/0 15KV 1/0 35KV |
#2 |
2.7 |
|
13768 |
LARGE RANGE JUMPER CLAMP CLEAR |
954 ACSR 36/1 |
6 SOLID .162 DIA |
4/0 15KV 2/0 25KV 1/0 35KV |
#2 15KV |
2.7 |
|
*NOTE: CLAMPS WILL ACCOMMODATE 4/0 STR. 15KV CABLE ONLY IF EPR (ETHYLENE, PROPYLENE RUBBER) INSULATED CABLE IS USED. |
||||||
|
**NOTE: IF 25KV OR 35KV CABLE IS REQUIRED LARGE RANGE CLAMPS MUST BE USED. |
||||||
