A36AHB-9104 A36AHB-9105天行健直销美国原装Johnson Controls多级温控

Models are available in ‘open’ construction for panel mounting. Single knob adjustment moves the entire staging band up and down within the range of the control. The differential on each stage and sequencing between stages are factory set. This permits the OEM to compleby engineer the cycling of their equipment without the hazard of field mis-adjustments and erratic sequencing. Features f Dust-tight SPDT switches f Cushion mounted f Operation from a single, liquid filled element f Case compensation standard on all models Application Designed for multi-stage thermostatic operation of electrically controlled equipment such as: f Packaged liquid chillers f Heat pumps f Electric duct heaters f Computer room airconditioners

Codes Range (°C) Adjustment code Cap. length (m) Bulb size (mm) Switch auto recycle Additional features 3-stage thermostats A36AGA-9101 -18 to 20 B1 5 125 5 A Armored PVC capillary A36AGA-9102 A36AGA-9103 15 to 35 C1 3.5 140 A36AGB-9103 -18 to 20 B2 125 3 A 4-stage thermostats A36AHA-9105 -18 to 20 B1 3.5 125 A36AHA-9107 -16 to 20 5 5 A Armored PVC capillary A36AHA-9108 15 to 35 C1 3.5 140 A36AHB-9103 10 to 95 D2 3 100 3 A Max. bulb temp.115 °C A36AHB-9104 -18 to 20 B2 3.5 125 Armored PVC capillary A36AHB-9105 5 Braided copper capillary A36AHB-9109 -
